SINGLE MODE SIMPLEX 1M MINI SC/APC 1*4 1*8 FIBER OPTIC SPLITTER
Description
1.Fiber Optic FBT splitter is a type of optical power management device that is fabricated using Fused Biconical Tape technology.
2. It features small size, high reliability, cheap cost and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting.
3.Rollball provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE
4.Rollball offers both tree and star type inline couplers/splitters with Rack mount box.
5. They provide a reliable solution to split/combine signals. The splitting ratio ranges from 1x2 to 1x32 ports for tree couplers, and from 2x2 up to 2x32 for star couplers. Available in single, dual, and tripple wavelength windows(1310/1490/1550nm).
Application
Long-haul Telecommunications
CATV Systems & Fiber Optic Sensors
Local Area Network
Charateristics
Low Excess loss
Low PDL
Environmentally stable
Good Thermal Stability
Specification
Nx4 N = 1,2,4 | Nx8 N = 1,2,8 | Nx16 N = 1,2 | Nx32 N = 1,2 | |
Operation Wavelength(nm) | 1310, 1490 and 1550nm | |||
| Banwidth(nm) | 1310±40,1490±10 and 1550±40 | |||
| Insertion loss(db) | ≤7.2 | ≤10.8 | ≤14.4 | ≤17 |
| Typical Insertion loss(db) | 0.3 | 0.45 | 0.6 | 0.75 |
| PDL(db) | ≤0.3 | ≤0.4 | ≤0.5 | ≤0.6 |
| Directivity(db) | ≥55 | |||
| Operation Temp | -40 to +85 degree | |||
| Lead length | 1meter, Customized on client’s request | |||
| Lead type | 900um, 2.0mm, 3.0mm loose tube | |||
