MECHANICAL FIBER OPTIC CONNECTOR-FIBER PRE-EMBEDED ESC250D/APC ESC250D/UPC FAST CONNECTOR
Application FTTx，Data Room Transformation
E-SC250D Fiber Optic Connector
Cutting 250um fiber 20.85mm, 125um fiber 7.7mm
Technical specification
Item | Parameter |
Cable Scope | 3.0 x 2.0 mm and 1.6*2.0mm Bow-type Drop Cable |
Size: | 51*9*7.55mm |
Fiber Diameter | 125μm ( 652 & 657 ) |
Coating Diameter | 250μm |
Mode | SM |
Operation Time | about 15s（exclude fiber presetting) |
Insertion Loss | ≤ 0.3dB（1310nm & 1550nm) |
Return Loss | ≤ -50dB for UPC, ≤ 55dB for APC |
Success Rate | >98% |
Reusable Times | >10 times |
Tighten Strength of Naked Fiber | >5 N |
Tensile Strength | >50 N |
Temperature | -40 ~ +85 C |
On-line Tensile Strength Test (20 N) | IL ≤ 0.3dB |
Mechanical Durability（500 times) | IL ≤ 0.3dB |
Drop Test（4m concrete floor, once each direction, three times total) | IL ≤ 0.3dB |
Relevant Solutions
Easy operating, The connector can be directly used in ONU, also with fasten strength more than 5 kg, it is widely used in FTTH project of network revolution. It also reduce the use of sockets and adapters, save cost of project.- With 86 standard socket and adapter, the connector makes connection between drop cable and patch cord. The 86 standard socket provides complete protection with its unique design.
- Applicable to connection with field mountable indoor cable, pigtail, patch cord and transformation of patch cord in data room and directly used in specific ONU.
