PATCH CORD SC/APC-SC/APC-SM-SX-GJFJH/GJYXFCH-XXM
1.Product features
•Low insertion loss and high return loss
•Excellent endface geometry parameter
•Special specificatiion availabel upon customer’srequest.
2.Applications
•Datatransmission Networks •Imagetransmission Networks
•CATV •Optical test instrument •Photoelectricautomatic control system
3.Product Sketch Map
Figure 1：SC/APC-SC/APC-SM-SX
Remarks:1.“L”stands for the order length；
4.Optical Performance
4.1 Optical performance index ofoptical fiber cabl
| Item | Unnit | Index | Remarks |
| Cable cutoff wavelength | nm | ≤1260 | |
| Bend radius | mm | ≥30 | |
| Attenuation value | dB/km | ≦0.36（1310nm）≦0.25（1550nm） | |
| Flame retardancy | / | Accord with UL94-V0 standard |
4.2 Optical performance index of connector
| Item | Unnit | Index | Remarks |
| Operating wavelength | nm | 1260～1650 | |
| Insertion loss | dB | ≤0.3 | |
| Return loss | dB | ≥50 | |
| Repeatability | dB | ≤0.1 | |
| Interchangeability | dB | ≤0.2 | |
| Working temperature | ℃ | -40～+85 |
Enclosure 1、Environmentalperformance of products
| Project | Test condition | Index | Monitoring proportion |
| High temperature | 85℃，96H | ΔIL≤0.2dB | Random monitoring of WIP 5pcs |
| Low temperature | -40℃，96H | ΔIL≤0.2dB | |
| Loop | -40～+85℃，3.5H/Cycle，40times loop | ΔIL≤0.2dB | |
| Hot and humid | 110℃，90%RH，2 atmospheric pressure，96H | ΔIL≤0.2dB | |
| Immersion | 43ºC, PH5.5，168H | ΔIL≤0.2dB |
Enclosure2、Mechanicalproperties of products
| Project | Test condition | Index | Monitoring proportion |
| To attack | 1.8m, three axial, 8 times / axial | ΔIL≤0.2dB | Random monitoring of WIP 5pcs |
| Vibration | 10 to 50HZ, 45 times /min, amplitude 0.75mm, three axial. Each axial 30min | ΔIL≤0.2dB | |
| Reverse | Distance machine 20 to 28cm, + 180 degrees, 6s/ times, 25 times | ΔIL≤0.2dB | |
| tensile | The distance from the plug is 20 to 28cm, 1min, and the load is 50N | ΔIL≤0.2dB |
Enclosure3、Reference standard
1.Domestic standard：
GB/T 12507.1-2000《Fibre optic cableconnectors - Part 1: General specification》
YD/T 1272.3-2005《Optical fiber connector part third: SC》
YD/T 2152-2010《Optical fiber connector reliability requirements andtest methods》
YD/T 1198-2002《echnical requirements for ferrule of optical fiberactive connecto》
YD/T 1258.1-2003《Indoor cable series is the first part of the total》
YD/T 1258.2-2003《Indoor cable series second part single core opticalfiber》
2.International standard:
GR-326-CORE 《General requirements for single-mode opticalfiber connectors and jumper assemblies》
