FTTH FIBER OPTIC DROP WIRE CABLE G657A FTTH SC UPC DROP CABLE PATCH CORD
Product description
1. Fiber optic patch cords are available in all standard connector styles, all standard fiber types and all standard cable configurations to meet all your interconnection needs. They are available in any length .
2.The patch cord are factory terminated, assembled, tested and inspected prior to shipment.
Characteristics:
(1) Ceramic Ferrule;
(2) High return loss;
(3) Low insertion loss;
(4) Good repeat-ability and and ex-changeability;
(5) Excellent Polished and 100% tested;
Technical parameter:
| Item | Information |
| Ferrule end-face | PC UPC APC |
| Connector type | FC,SC,LC,ST,MTRJ,MU,E2000,MPO,DIN,D4 and SMA |
| Cable type | SX/LSZH |
| Mode | SM:9/125 |
| Cable diameter | 2.0mm,3.0mm |
| Insertion loss | ≤0.2 and ≤0.3dB |
| Return loss | ≥50 and ≥65dB |
| Exchangeability | ≤0.2dB |
| ≤0.2dB | ≤0.2dB |
| Operating temperature | -40 to 75℃ |
| Storage temperature | -45 to 85℃ |
| Tensile force | 50N/static state 30N/used state |
