Cable construction

2~12 fibers

jelly filled

fiber contained central loose tube

Water blocking yarn

PE outer sheath

 fig 8 type

one steel wire suspension line

G652D SM fiber, detailed specification on your request.

 Features:

Ø GYXTC8Y features the centrally situated loose tube with good excess length and minimize the influence of lateral crush

Ø The water blocking yarn provides good water resistant performance.

Ø The cross section shows figure 8. Stranded wires as self supporting member providing excellent strain performance and convenient installation for this GYXTC8Y fiber cable.

Cable Performance

Rural communication, local trunk line, CATV & computer networks system

Application                       : self-supporting aerial

Installation method               : self-supporting aerial

Operating temperature             : -40°C ~ +70°C

Lifetime                           : above 30 years
