SINGLE MODE ARSS CABLE FIBER OPTIC CABLE FOR ARIEL INSTALLATION 4-144 CORES
Cable Description
ARSS cable is loose tube stranded. Fibers,250μm, arepositioned into a loose tube made of high modulus plastics. The tubes arefilled with a water-resistant filling compound. The tubes and fillers arestranded around a FRP (Fiber Reinforced Plastic) as a non-metallic centralstrength member into a compact and circular cable core. After the cable core isfilled with filling compound, stranded layer of aramid yarns are applied overthe elements as strength member, then it is covered with corrugated steel tape.the cable is completed with PE outer sheath.
1.1 Dimensionand Properties
Physical | Fiber count | 24 F G.652D |
No of loose tube / filler No. | 2/3 | |
Fiber No . per tube | 6 | |
Strength member | Aramid yarns | |
Cable OD | 10.0±0.3 mm | |
Cable weight | Approx . 67 kg/km | |
Operation temperature range | - 40 deg C to + 70 deg C | |
Installation temperature range | - 10 deg C to + 60 deg C | |
Transport and storage temperature range | - 40 deg C to + 70 deg C | |
Mechanical | Max . Tensile load | Installation : 1.8 KN |
Crush resistance | 1000 N/10cm | |
Minimal installation bending radius | 20 × OD | |
Minimal operation bending radius | 10 × OD |
Color code scheme: According to EIA/TIA 598
No. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Fiber color | Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Violet | Pink | Aqua |
Tube color | Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Violet | Pink | Aqua |
1.2 CableApplications
Aerial
2. Optical Characteristics& Technical Parameters
2.1Optical Characteristics
Fiber Type | G.652 | G655 | 50/125μm | 62.5/125μm | |
Attenuation(+20℃) | @850nm | ≤3.0 db/km | ≤3.3 db/km | ||
@1300nm | ≤1.0 db/km | ≤1.0 db/km | |||
@1310nm | ≤3.6 db/km | ≤0.40 db/km | |||
@1550nm | ≤0.22 db/km | ≤0.23 db/km | |||
Bandwidth | @850nm | ≥500MHz.km | ≥200MHz.km | ||
@1300nm | ≥500MHz.km | ≥500MHz.km | |||
Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
Cable Cut-off Wavelength | ≤1260 nm | ≤1450 nm | |||
3. Packing and shipping
3.1 The cables are packed in wooden drums.
3.2 delivery length is 4km/drum
3.3 Sheath Marking
The sheath marking are hotstamped on the sheath at one meter interval with white color. The accuracy ofthe length marking shall be 0 ~ +1%.
Re-marking is yellow color, ifnecessary.
RUX *** xxFIBRE Month/Year XXXXM
l RUX: Manufacturer’s Name
l ***: Customer’s name
l xxFIBRE: Fiber count
l Month/Year: Manufacturedate
l XXXXM: The figure ofmeter.
