AERIAL OR DUCT OUTDOOR CENTRAL LOOSE TUBE SINGLE MODE FIBER OPTIC CABLE GYXTY
Product description
GYXTY
structure with central tube
non-metal strength member
PE jacket
Application
duct, non self-supporting aerial installation, groove, tunnel, leading in , cable trench
characteristics
excellent water-blocking performance
nice tensile and temperature performance
note: other types of fiber can be provided according to the customer's demands
Technical parameter
| fiber | structure | nominal diameter (mm) | nominal weight(kg/km) | long-term/short-term permitted tensile (N) | long-term/short-term permitted crush(N) | static /dynamic bend radius(mm) |
| 2-12 | central tube | 6.9 | 36.5 | 600/1500 | 300/1000 | 10D/20D |
| 20-24 | central tube | 7.2 | 40.1 | 600/1500 | 300/1000 | 10D/20D |
| item | 62.5µm(OM1) 850nm/1300nm | 50µm(OM2) 850nm/1300nm | G.652 1310nm/1550nm | G.655 1550nm/1625nm |
attenuation of max value (dB/km) | 3.5/1.5 | 3.5/1.5 | 0.36/0.22 | 0.22/0.26 |
attenuation of typical value (dB/km) | 3.5/1.5 | 3.0/1.0 | 0.35/0.21 | 0.21/0.24 |
Color code scheme: According to EIA/TIA 598
No. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Fiber color | Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Violet | Pink | Aqua |
Tube color | Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Violet | Pink | Aqua |
Packing and shipping
1 The cables are packed in wooden drums.
2 Standard delivery length is 2km/drum or per customer’s requirements.
3 Sheath Marking
The sheath marking are hot stamped on the sheath at one meter interval with white color. The accuracy of the length marking shall be 0 ~ +1%.Re-marking is yellow color, if necessary.
RUX *** xx FIBRE Month/Year XXXXM
RUX: Manufacturer’s Name
***: Customer’s name
XX FIBRE: Fiber count
Month/Year: Manufacture date
XXXXM: meter.length
