SINGLE MODE FTTH INDOOR DROP FIBER OPTICAL CABLE

OEM available factory price singlemode FTTH fiber optical cable price per meter


Product description

The optical fiber unit is positioned in the center, two parallel Fiber Reinforced Plastics (FRP)  or steel wire are placed at the two sides.  Then, the cable is completed with a black or color LSZH sheath.


Technical parameter

Fiber Type

Attenuation

OFL

Valid mode
band width

10G Ethernet
 link length SX

Min. bending
 radius

Condition

1310/1550nm

850/1300nm

850/1300nm

850nm

850nm


Typical

Max.

Typical

Max.

Unit

dB/km

dB/km

dB/km

dB/km

MHZ.km

MHZ.km

m

mm

G657A1

0.36/0.22

0.5/0.4






10

G657A2

0.36/0.22

0.5/0.4






7.5

OM3



3.0/1.0

3.5/1.5

1500/500

2000

300

30

OM4



3.0/1.0

3.5/1.5

3500/500

4700

550

30


Characteristics

1. Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property

2. Two parallel strength members  ensure good performance of crush resistance to protect the fiber

3. Simple structure, light weight and high practicability

4. Novel flute design, easily strip and splice, simplify the installation and maintenance


Application

1. Access network , fiber to the home

2. Support the Internet , CATV , telephone and more network service in the future.


SINGLE MODE FTTH INDOOR DROP FIBER OPTICAL CABLE
