TELECOM OUTDOOR 3 STEEL WIRES FTTH FIBER OPTIC CABLE FOR SALE IN CHINA
Cable construction
The optical fiber unit is positioned in the center, two parallel Fiber Reinforced Plastics (FRP) steel wires are placed at the two sides. Then, the cable is completed with a black or color LSZH or other materials sheath.
Technical parameter
Fiber Type | Attenuation | OFL | Valid mode | 10G Ethernet | Min. bending | |||
Condition | 1310/1550nm | 850/1300nm | 850/1300nm | 850nm | 850nm | |||
Typical | Max. | Typical | Max. | |||||
Unit | dB/km | dB/km | dB/km | dB/km | MHZ.km | MHZ.km | m | mm |
G657A1 | 0.36/0.22 | 0.5/0.4 | 10 | |||||
G657A2 | 0.36/0.22 | 0.5/0.4 | 7.5 | |||||
OM3 | 3.0/1.0 | 3.5/1.5 | ≥1500/500 | ≥2000 | ≤300 | 30 | ||
OM4 | 3.0/1.0 | 3.5/1.5 | ≥3500/500 | ≥4700 | ≤550 | 30 | ||
Characteristics
1. Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
2. Two parallel strength members ensure good performance of crush resistance to protect the fiber
3. Simple structure, light weight and high practicability
4. Novel flute design, easily strip and splice, simplify the installation and maintenance
Application
1. Access network , fiber to the home
2. Support the Internet , CATV , telephone and more network service in the future.
