AIR BLOWN FIBER UNIT (ABF) FIBER UNITS/BUNDLES-FU
Features andBenefits
1. 2、4、6、8 and 12 fibres options.
2. Stable structure, good mechanical and temperature performance.
3. Designed with special grooves to advance blowing distance
4. Lightweight and properstiffness , repeat installation.
5. Designed with no gel, easy stripping and handling.
6. Better costs advantage compared to traditional product.
7. Complete accessories, less manpower, lower installation time.
Technical Parameter
Fibre Unit Structure
• Basic Performance
Fibre Count |
2 Fibres |
4 Fibres |
6 Fibres |
8 Fibres |
12 Fibres | |
Outer Diameter | (mm) | 1.15士0.05 | 1.15士0.05 | 1.35士0.05 | 1.50士0.05 | 1.65士0.05 |
Weight | (g/m) | 1.0 | 1.0 | 1.3 | 1.8 | 2.2 |
Min Bend radius (mm) | Dynamic: 20 times of cable diameter; Static: 10 times of cable diameter | |||||
Temperature | Storage:-30C � +70C Operation:-30C � +70C Installation:-5C � +50C | |||||
Cable service life (estimate value) |
25 years | |||||
Note: It is recommended that the structure of 2 fibres unit consist of 2 filled fibres, for it is proved that 2 fibres unit with 2filled fibres is better than the one with zero or one filled fibre in the blowing performance and the fibre stripping-ability | ||||||
• Blowing Test
Fibre Count |
2 Fibres |
4 Fibres |
6 Fibres |
8 Fibres |
12 Fibres | |
Test equipment | PLUMETTAZ:UM25, | ERICSSON:F, | CATWAY:FBT-1.1 | |||
Standard duct |
5.0/3.5 mm | |||||
Pressure |
7bar / 10bar | |||||
Typical blowing distance |
500m / 1000 m |
500m / 1000m |
500m / 1000m |
500m / 1000m |
500m / 800m | |
Typical blowing time |
10 min / 18 min |
10 min / 18 min |
12 min / 18 min |
13 min / 18 min |
15 min / 20 min | |
• MechanicalPerformance
Test |
Standard |
Parameters |
Test Results |
Tension | EN 18700 A1/501
IEC 60794-1-2-E1 |
Load is 1xW |
Additional attenuation ::0.05dB after test |
Bend |
IEC 60794-1-2--E11A | Diam 40mmx3turns 5 cycles at 20C |
Additional attenuation ::0.05dB,after test |
Crush |
IEC 60794-1-2-E3 |
100 N, 60s |
Additional attenuation ::0.05dB,after test |
All optical testing proceeded at 1550 nm | |||
• Environment Performance
Test |
Standard |
Parameters |
Test Results |
Temperature Cycle |
IEC 60794-1-2-F1 | -300C, +700C,
(2 cycles) | Absolute attenuation ::0.5dB/km,during test
Additional attenuation ::0.1dB/km, during and aftertest |
Water Soak |
IEC 60794-5 | 1000 hours in water, 18C�22C | (Test after temp cycle) ::0.07dB/km
Change compared to start value |
Damp Heat Cycle |
IEC 60068-2-38 | 250C, 650C, 250C,650C,
250C,-100C, 250C | Absolute attenuation ::0.5dB/km,during test
Additional attenuation ::0.1dB/km, during and aftertest |
All optical testing proceeded at 1550 nm | |||
• Fibre Color Code (Fibre colors can also be determined by customer)
NO. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
Color | Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Violet | Pink | Aqua |
• Sheath Color: Yellow/ Green/ Natural/ Customized
• SheathMarking
The outer sheathis markedin1 meter intervals as follows:
RUX ABF typeoffibreandnumber [MM-YYYY] =lengthmarkinginmeter= Example: RUX ABF G652D 4F [04- 2014] =1888m=
• Delivery Length
Standard delivery lengths are1000m, 2000m, 3000m, 4000m,6000m with a tolerance of -0.5�+1%. For moreoptions, please contact thecustomer service.
