Structure:

1. 600μm or 900μm tight buffer in the center

2. Water blocking yarn and water blocking tape applied for cheaper solution

    (Aramid yarn as strength member available for longer span request)

3. Jacket material: PE or LSZH available

Features:

1.Indoor and outdoor dual-use;

2.Good mechanical and environmental performance;

3.Meet the requirements of RoSH.

Application:

As access cable in access network or premises network;

As building cable in premises distribution system, such as shaft cabling, drainage tubes cabling , trough cabling, wall cabling, ceiling cabling, especially in the environment of high requirements of flexibility and bending properties;

Used in communication between outdoor AP and ONT.

Specification:

A wide ranged of optical fiber types are available (G.652D, G.657, A1a, A1b etc.)

Strength Member: Aramid yarn

Outer diameter: Customizable

Material: LSZH or PE

Color: Black

Performance:

Installation temperature(℃): -10~+50

Operating temperature(℃): -40~+70

Transportation and storage temperature(℃): -20~+60

Min. bending radius(mm): 20D(Dynamic), 10D(Static)

Max. crush resistance(N/10cm): 300 (Long term), 1000 (Short term)
