The armored fiber optic cable which “can befreely used like electrical wire”,this item is protected by flexible stainlesssteel tube.Compare with the regular fiber cable,it have advantage performanceof High compression &impact resistance,anti-bug. With fixedstandard 3mm fiber optic connector,it widely used in various terrible environment.

Structure: 0.9mm tight-buffered cable*2+ stainless steel tube+ 6 branchArmyarn+ jacket

Specifications：

1).Tight-buffered cable：

0.9mm tight-buffered

Material:PVC or LSZH

General attenuation:1310 nm≤0.4dB/km;1550 nm≤0.25dB/km

2).Stainless steel tube：

material：SUS204

Outer diameter（D）：2.80±0.1mm

Insider diameter (d): 2.20±0.1mm

Thickness（t）：0.30±0.02mm

Gap(p)：0.20±0.05mm

Compression resistant strength:≥3000N/100MM

3). Armyarn：

model:1000dtex

Number:6 branchoutside the stainless steel tube

Tensile strength:Short term:≥500N: long  term:≥200N.

4). jacket：

Material：PVC,LSZH,,PE, TPU

Color:black, blue or customized

Thickness（t）：0.80±0.10mm

Outer diameter（D）：4.8±0.2mm or 6.0±0.2mm

Operating temperature:-20℃～+70℃

Weight:28-42kg/KMapprox
