1, cable extrusion machine installation instructions
Adjust the center height of other machines based on the height of the center of the extruder. After adjustment, install the anchor screw to calibrate the horizontal screw and screw the ground screw. Then press the plane to the ground. After checking that there are no abnormalities in all parts of the equipment, clean the equipment.
2, cable extrusion machine electrical cabinet and equipment wiring instructions
a. Please strictly connect and connect the electrical cabinet and equipment terminal diagram.
b. The connection between the electrical cabinets is prepared, and the connection between the electrical cabinets and the equipment is provided by the customer.
c. Each motor and equipment casing shall be grounded in accordance with national standards.
d. The control line and power line should pay attention to the distribution line to prevent interference.
e. Long-distance transportation may cause the screws to loosen, please check and tighten.
f. All wiring should be marked with the same wiring terminal.
g. After the wiring is made outdoors, the multimeter should be strictly inspected. It is strictly forbidden to check with any means of charging.
h. It is strictly forbidden to change the wiring inside the cabinet.
3, cable extruder maintenance instructions
The cable extruder can operate continuously for a long time, and it is necessary to check whether the screws of each device are loose and the flexibility of operation.
l Extrusion barrel
Before the screw is installed, the inner surface of the barrel must be cleaned with compressed air. Use a tie rod brush to scrape off the coarse dirt. The local damage can be removed by polishing, and the small amount of material must be removed.
l heaters and sensors
The clamping bolts of the heater should be inspected frequently. If it is loose, it must be tightened. Keep the base surface of the temperature sensor seat hole clean, otherwise the temperature indication on the regulator will be invalid.
The surface of the screw has grooves, material damage and damage caused by foreign matter, which can be repaired by grinding and polishing. Each time the spare part is used to pull out the screw, the hardness of the rod is extracted from the end of the gear box, and the soft tool is used to remove the residue.
l Remove residues from the cooling water.
Fill the gearbox in the worm gear box on the extruder and the storage rack, and change the oil every 800-1000 hours.
